Parallel programming · 2025

Ray Tracer in C

Rendering scenes of coloured spheres from scratch — vector maths, memory-mapped output and OpenMP.

My role
Sole author
Date
2025
Stack
C · OpenMP · mmap · Make

TL;DR

  • A ray tracer written in plain C: one ray per pixel, intersected with every sphere in the scene.
  • Rendering is parallelised with a single OpenMP directive; output is written as a binary PPM through mmap.
  • Timing experiments showed that the simplest parallel schedule was also the fastest.
Coloured spheres rendered by the ray tracer, nearer spheres hiding the ones behind

How it works

  1. Rays. The camera sits at the origin. For every pixel, a ray starts from the camera and passes through the corresponding point of a viewport, a rectangle placed in front of the camera at distance z.
  2. Intersections. For each sphere, the ray hits it where t solves (V·V)t² − 2(C·V)t + (C·C − r²) = 0, with V the ray direction, C the centre and r the radius.
  3. Colour. The pixel takes the colour of the nearest sphere hit, or the background colour if there is none.

Scenes are described in a small text format:

VP 2 1.25 1          # viewport width, height and distance
BG 255 255 255       # background colour
OBJ_N 7              # number of spheres
S 0 0 5 1 255 0 0    # sphere: centre x y z, radius, colour R G B

Code structure

  • vector.c — a 3D vector type and its operations: sum, difference, dot product, scaling, normalisation.
  • scene.c — loading a scene from file, with checks and cleanup on every error path; the ray–sphere intersection and the tracing loop. Colours are packed structs, so a row of pixels is exactly three bytes per pixel.
  • ppm.c — the image is written as a binary PPM (P6): the file is sized, mapped into memory with mmap, and pixels are written straight into it.
  • main.c — command line, orchestration and parallelism.

Parallelisation

Every pixel is independent, so the double loop over rows and columns is parallelised with:

#pragma omp parallel for collapse(2)
for (int j = 0; j < height; j++)
    for (int i = 0; i < width; i++)
        /* compute the colour of pixel (i, j) */

I timed several variants. Dynamic scheduling brought no improvement: every pixel costs about the same, so there is no load imbalance for it to fix, only overhead. collapse(2) alone was the best option.

What I took away

  • Measure before optimising. The “smarter” schedule was slower; only timing showed it.
  • Memory layout is part of the algorithm. Packed colours and a memory-mapped file make the output step a plain write into an array.
  • C forces you to own every resource. Each allocation needed a matching free on every error path, which made me much more careful about failure handling.
